Flow • Level • Pressure Switch

Flow Switches

Series FS pre-set Flow Switch is available in PVC or CPVC, with flow rate range from .7 - 25 GPM. Switches offered from 5 VDC to 240 VAC.

For complete information please click here (English)

ESPANOL

Series FSA adjustable Flow Switch is available in PVC or CPVC, with flow rate range from 8 - 1900 GPM, designed for pipe size 1" through 10". Offers continuous adjustment during operation; SPDT 15 amp switching capacity model or Dry Computer/PLC Interface model.

For complete information please click here (English)

ESPANOL

Series FS and FSA NEMA 4 Flow Switches have no wetted metals; switch is isolated from liquid by EPOCAP® epoxy. For chemical compatibility information, please click here and refer to far right column headed "epoxy." Both models carry a three year guarantee.

Level Switch

Series LLS with pivot pin design features SPST reed switch for 120/240 VAC 50 Watt power or optional DC dry circuit for computer/PLC interface. 1/4" NPT connection with choice of PVC or Noryl body material. Rugged, corrosion-resistant design has no wetted metals and includes three year guarantee.

For complete information please click here (English)

ESPANOL

Pressure Switch

Series SWT 1/2" piping connection with PTFE diaphragm, for pressures to 150 PSI. Versatile snap-action 16 Amp/3 terminal switch is standard; 25 Amp and low deadband 3 Amp switches optional. Heavy duty construction features no wetted metal parts and three year guarantee.

For complete information please click here
